A 1.3inch OLED Display Module for Raspberry Pi Pico

by rp2040guy71

In this article we look at a 1.3inch OLED Display Module For the Raspberry Pi Pico from waveshare, it measures 64×128 Pixels, it uses SPI/I2C Interface.

It is a 1.3″ OLED Display Module which uses a SH1107 Driver and has a SPI or I2C bus option.

The board also has 2 buttons that the user can use for their needs – User key 0 and 1 in the pinout below.

Specifications

Operating Voltage:3.3V
Communication Interface: 4-Wire SPI, I2C
Display Panel: OLED
Driver: SH1107
Resolution: 64×128 pixels

Raspberry Pi Pico C/C++ and MicroPython demo code examples are available to help you get started from the link at the bottom.

Code

This is the default SPI example – it might be easier to view the code at https://github.com/programmershelp/rp2040/tree/main/Hardware/Pico-OLED-1.3



[codesyntax lang=”python”]

from machine import Pin,SPI
import framebuf
import time

DC = 8
RST = 12
MOSI = 11
SCK = 10
CS = 9


class OLED_1inch3(framebuf.FrameBuffer):
    def __init__(self):
        self.width = 128
        self.height = 64

        self.cs = Pin(CS,Pin.OUT)
        self.rst = Pin(RST,Pin.OUT)

        self.cs(1)
        self.spi = SPI(1)
        self.spi = SPI(1,2000_000)
        self.spi = SPI(1,20000_000,polarity=0, phase=0,sck=Pin(SCK),mosi=Pin(MOSI),miso=None)
        self.dc = Pin(DC,Pin.OUT)
        self.dc(1)
        self.buffer = bytearray(self.height * self.width // 8)
        super().__init__(self.buffer, self.width, self.height, framebuf.MONO_HMSB)
        self.init_display()

        self.white =   0xffff
        self.balck =   0x0000

    def write_cmd(self, cmd):
        self.cs(1)
        self.dc(0)
        self.cs(0)
        self.spi.write(bytearray([cmd]))
        self.cs(1)

    def write_data(self, buf):
        self.cs(1)
        self.dc(1)
        self.cs(0)
        self.spi.write(bytearray([buf]))
        self.cs(1)

    def init_display(self):
        """Initialize dispaly"""
        self.rst(1)
        time.sleep(0.001)
        self.rst(0)
        time.sleep(0.01)
        self.rst(1)

        self.write_cmd(0xAE)#turn off OLED display

        self.write_cmd(0x00)   #set lower column address
        self.write_cmd(0x10)   #set higher column address

        self.write_cmd(0xB0)   #set page address

        self.write_cmd(0xdc)    #et display start line
        self.write_cmd(0x00)
        self.write_cmd(0x81)    #contract control
        self.write_cmd(0x6f)    #128
        self.write_cmd(0x21)    # Set Memory addressing mode (0x20/0x21) #

        self.write_cmd(0xa0)    #set segment remap
        self.write_cmd(0xc0)    #Com scan direction
        self.write_cmd(0xa4)   #Disable Entire Display On (0xA4/0xA5)

        self.write_cmd(0xa6)    #normal / reverse
        self.write_cmd(0xa8)    #multiplex ratio
        self.write_cmd(0x3f)    #duty = 1/64

        self.write_cmd(0xd3)    #set display offset
        self.write_cmd(0x60)

        self.write_cmd(0xd5)    #set osc division
        self.write_cmd(0x41)

        self.write_cmd(0xd9)    #set pre-charge period
        self.write_cmd(0x22)

        self.write_cmd(0xdb)    #set vcomh
        self.write_cmd(0x35)

        self.write_cmd(0xad)    #set charge pump enable
        self.write_cmd(0x8a)    #Set DC-DC enable (a=0:disable; a=1:enable)
        self.write_cmd(0XAF)
    def show(self):
        self.write_cmd(0xb0)
        for page in range(0,64):
            self.column = 63 - page
            self.write_cmd(0x00 + (self.column & 0x0f))
            self.write_cmd(0x10 + (self.column >> 4))
            for num in range(0,16):
                self.write_data(self.buffer[page*16+num])


if __name__=='__main__':

    OLED = OLED_1inch3()
    OLED.fill(0x0000)
    OLED.show()
    OLED.rect(0,0,128,64,OLED.white)
    time.sleep(0.5)
    OLED.show()
    OLED.rect(10,22,20,20,OLED.white)
    time.sleep(0.5)
    OLED.show()
    OLED.fill_rect(40,22,20,20,OLED.white)
    time.sleep(0.5)
    OLED.show()
    OLED.rect(70,22,20,20,OLED.white)
    time.sleep(0.5)
    OLED.show()
    OLED.fill_rect(100,22,20,20,OLED.white)
    time.sleep(0.5)
    OLED.show()
    time.sleep(1)

    OLED.fill(0x0000)
    OLED.line(0,0,5,64,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(0,0,20,64,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(0,0,35,64,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(0,0,65,64,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(0,0,95,64,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(0,0,125,64,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(0,0,125,41,OLED.white)
    OLED.show()
    time.sleep(0.1)
    OLED.line(0,0,125,21,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(0,0,125,3,OLED.white)
    OLED.show()
    time.sleep(0.01)

    OLED.line(127,1,125,64,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(127,1,110,64,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(127,1,95,64,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(127,1,65,64,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(127,1,35,64,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(127,1,1,64,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(127,1,1,44,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(127,1,1,24,OLED.white)
    OLED.show()
    time.sleep(0.01)
    OLED.line(127,1,1,3,OLED.white)
    OLED.show()
    time.sleep(1)
    OLED.fill(0x0000)
    OLED.text("128 x 64 Pixels",1,10,OLED.white)
    OLED.text("Pico-OLED-1.3",1,27,OLED.white)
    OLED.text("SH1107",1,44,OLED.white)
    OLED.show()

    time.sleep(1)
    OLED.fill(0x0000)
    keyA = Pin(15,Pin.IN,Pin.PULL_UP)
    keyB = Pin(17,Pin.IN,Pin.PULL_UP)
    while(1):
        if keyA.value() == 0:
            OLED.fill_rect(0,0,128,20,OLED.white)
            print("A")
        else :
            OLED.fill_rect(0,0,128,20,OLED.balck)


        if(keyB.value() == 0):
            OLED.fill_rect(0,44,128,20,OLED.white)
            print("B")
        else :
            OLED.fill_rect(0,44,128,20,OLED.balck)
        OLED.fill_rect(0,22,128,20,OLED.white)
        OLED.text("press the button",0,28,OLED.balck)

        OLED.show()


    time.sleep(1)
    OLED.fill(0xFFFF)





[/codesyntax]

Products

You can pick up the PICO OLED 1.3 display from the link below, it will cost about $15

Name Link
Pico Raspberry Pi Pico Development Board A Low-Cost High-Performance Microcontroller Board RP2040 Cortex-M0+ Dual-Core ARM Processor
PICO OLED 1.3 Waveshare 1.3inch OLED Display Module For Raspberry Pi Pico



Link

https://www.waveshare.com/wiki/Pico-OLED-1.3

Schematic

SH1107D Datasheet

Demo codes
